Hurley H2O Dinghy Davit System

(4 customer reviews)


Currency Calculator

From USD

Hurley H2O Dinghy Davit ® (Hurley’s 2nd Option)  . . .
a classy yet functional design!

Hurley H2O Dinghy Davit ® is a rugged dinghy davit system that lets you lift and pull your dinghy on for easy storage or just push off for launching.  Easily mounted on the swim platform and can be installed while the vessel is in the water.

  • Superior Quality and Craftsmanship
  • Can be used for Soft or Rigid Tenders
  • Position Adjusting Chock System adjusts to Rigid Hull Configuration for Hard Bottoms
  • Wide Footprint for Soft Bottoms
  • Adjustable Cradle Angles for Easy Deployment & Retrieval
  • Independent Cradles with Rollers
  • Roller Wells have Weep Holes for Water Drainage
  • Multiple Mount Sizes to Accommodate Different Size Platforms
  • Can Be Used on Hydraulic Swim Platforms with Existing Channels to Remove Those Ugly and Dangerous Chocks
  • Numerous adjustments for your convenience
  • Weighs in at only 15 pounds
  • Two-year warranty

Review our Recommended Tie-Down Method.

Note: You must select your Mount Size to see pricing and/or to add it to your cart.  Instructions to properly select your Mount Size are below!

Purchase includes: H2O Dinghy Davit ®, Mounts and Mounting Plates. Mounting bolts are not included.   Two-year warranty.  Made in the U.S.A.

Need help?  Complete our Davit Worksheet to help us determine which components you’ll need.

Ask about our special Highfield Dinghy Davit Inserts.


⚓️  Shop for “H2O Accessories”


Hurley H2O Dinghy Davit ®

The Hurley H2O Dinghy Davit ® has a Sleek Euro Design, Marine Grade High-Density Polyethylene Cradles, and Stainless Steel Components, Functions as Good as it Looks, and is Impervious to Harsh Environments.  Our revolutionary new stainless steel mounting system provides a quick release, leaving a very small footprint profile that could pull a barge.  Each mount footprint requires only two bolts for the install and only stands 5/8" high leaving a clear deck for any activity. Mount Covers are available.

The H2O has been designed for either soft or hard bottoms.  The soft bottom model offers a wide 3" footprint for your tender.  This helps in the support of the transom where most of the weight is and is much easier on the bottom.  If you start out with a soft bottom tender and upgrade to a hard bottom, no problem, remove the soft bottom pads and add the adjustable Chock Pads.

The Hurley H2O Dinghy Davit ® is easily mounted on the swim platform.  This hassle-free system lets you lift and pull your dinghy on for easy storage or just push off for launching.  Always available in an emergency.

Featured in the Product Showcase of the 2012 Miami International Boat Show . . .

If you have a lip on the outer edge of your platform, let us know how high it is and we will ship you free shims with your purchase. 1/4" & 3/8" shims available.   The difficulty of retrieval depends upon the weight of your dinghy and the height of your platform off the water.

Hurley Marine, Inc. pioneered the original swim platform davit of this style back in 2002.  Since the original, our research and development (R&D) team has worked to provide the consumer with the very best in design and quality for versatility and years of enjoyment.  We believe that you should enjoy taking your tender along but not sacrificing your vessel's performance.  The low profile storage position on our davits provides exceptional stern visibility with none of the performance-robbing kite flying drag.  There are no other dinghy davits that compare!.  Make Sure it says "HURLEY" . . .   Sold Worldwide!

Fill out our Davit Worksheet Form to help us determine which system and mount size would be best for you.

H2O Instruction Manual  »
Davit Worksheet Form  »
Dinghy Davit Gallery  »

Please send us pictures once you have your new davit installed.

Additional Information


Properly Measuring for your Davit Mount Size

Key Dimensions Needed

Key Dimensions to Determine Mount Size

A = Swim platforms internal width
B = Platforms depth (transom to edge)
C = Distance from top of platform to the water
D = Beam of dinghy

To determine which mount system will work best for you, measure the beam of your dinghy, divide by 2 and add 4 inches. Now measure your platform (transom to the end).

You must add a number below to your platform length figure in order to determine which mount to use.

Example: If your dinghy width is 60″ then divide by 2 + 4″ = 34″. Swim platform is 32″. By adding 2″ to the platform this would make it equal to the dinghy width of 34″ so then you would have chosen the 6″ mount.

• 0 – 2″ for the 6″ Mount
• 2″-4″ for the 8″ Xtensions
• 4″-6″ for the 10″ Xtensions
• 6″+ for the 36″ Xtensions

Hint: 4 inches of the mount must be used to secure to the platform.

If you have a lip on the upper edge of your platform, let us know how high it is and we will include free shims with your purchase.

If your having problems determining the right mount size, fillout our Davit Worksheet Form or give us a hail at 1.906.553.6249

4 reviews for Hurley H2O Dinghy Davit System

  1. Robert M. Toedter

    Great products are characterized by their elegant simplicity of design and ease of use. The Hurley Marine H20 Davits check all of the boxes. With the help and advice given by Hurley’s staff, the installation was straight-forward and easy. Our dinghy (Zodiac 340 Aluminum Bottom with Mercury 5HP outboard) pulled-up easily and without undue effort onto the swim platform. Also purchased were the cleats that attach to the mounting plates to tie the dinghy to while it’s in the water, and mounting plate covers to prevent people from stubbing their toes on the mounting plates. If you have a swim platform, then the Hurley Marine H20 Davit system is a winner!

  2. Randy Duncan

    Hi Leslie,

    Thank you for all of your assistance in helping us in selection of the right Davit for our boat a 2018 Back Cove 32.

    Attached is a photo of us proceeding upriver at approximately 15 knots on Sojourn on the Columbia River. The H2O davit works great for our needs and the dinghy is an easy on and off of our Zodiac fiberglass 8’10” Cadet RIB equipped with a 6 hp Yamaha four-stroke engine.

    Best, Randy Duncan
    M/V Sojourn, Portland Oregon

  3. rodrigo

    I’m very satisfied with my H2O’s, they are light and well made. When not in use the hardware on my platform is almost out of sight, this summer I had a chance to use them a lot, I’m very pleased with the product. I recommend this to everyone. and I also commend the good service by Mr. Hurley.

  4. Gordon

    The Hurley Davits are the best made ones on the market! And customer service is so great. I send all my boating friends to hurley!
